TRI-BEAM™ is a scientifically advanced Q-Switched Nd:YAG Laser that boasts exceptional results in:

  • Advanced and rapid tattoo removal
  • Treatment of epidermal and dermal pigmentation and freckles
  • Non-abrasive skin rejuvenation and resurfacing
  • Treatment of acne and enlarged pores
  • Diminishing fine lines and wrinkles
  • Regeneration of damaged cells and collagen
  • Lifting, tightening and improving tone of ageing skin

TRI-BEAM™ equips operators with a sleek and stylish design and user-friendly system – the multiple operation modes allows patients to experience a wide range of treatments that can be specifically targeted to their individual concerns.

TRI-BEAM™ boasts unique auto-sensor spot size detection allowing operators intuitive ease-of-use and personalised treatment to the patient’s condition, while the zoom collimated handpiece enables an all-round faster and more comfortable treatment experience. TRI-BEAM™ is also very low maintenance and requires minimum consumables, which greatly reduces operating costs for salon, spa, clinic and practice owners.

Call AU 1300 655 013, NZ 0800 398 749
or click here for a free, no obligation quote

Free Quote

The Global Beauty Group
Client Experiences

Discover More


One of a Kind Rich-PTP™ Technology

Rich-PTP™, which stands for Photoacoustic Therapy Pulse is a unique and completely exclusive feature of TRI-BEAM™. It has achieved unmatched success in clinical efficacy compared to other Q-Switch Nd:YAG lasers. Rich-PTP™ specifically shatters targeted chromophores and maximises photo-acoustic effect resulting in a faster, safer and more effective toning of the treatment area and superior aesthetic results thanks to this extremely powerful and advanced energy. So powerful, the Rich-PTP™ technology delivers 2-pulse energy and up to 20Hz of power in a much shorter time, which minimises damage to the epidermal cells while selectively targeting and destroying pigmented lesions.

In addition to a 1060nm capability for removing dark ink and a 532nm capability for red and orange ink, the TRI-BEAM™ also has 585nm and 650nm dye wavelength handpieces available. The 585nm wavelength handpiece treats sky blue ink, while the 650nm wavelength handpiece targets green ink, allowing for effective full-colour tattoo removal.

TRI-BEAM™ is also available with an additional fractional handpiece. The fractional handpiece assists in the delivery of exceptional treatment outcomes, while at the same time reducing the possibility of post-inflammatory hyperpigmentation complications associated with less sophisticated tattoo removal devices.

Gen Technique™ Philosophy via Quasi-Long Pulse

Quasi-Long Pulse and Gen Technique™ is a functional combination of thermal lifting and toning achieved through fundamental selective photothermolysis. Gen Technique™ is fantastic for treating pigmented lesions as well as common skin rejuvenation requests including skin lifting, skin toning and reducing enlarged pores. Expect better efficacy with the integrated Gen Technique™ in the TRI-BEAM™ system when it comes to peeling, lifting, treating and diminishing deep pigmentation and regenerating collagen production.

Before and After – Treatments with the TRI-BEAM™

Technical Specifications

  • Dimensions: H 790mm x W 310mm x L 690mm (without articulated arm)
  • Weight: 110kg
  • Electrical power: 220V, Single Phase, 50/60Hz, 20 Amps @ 220V AC
  • Laser medium: Nd:YAG Q-Switched
  • Operating parameters: Q-Switched & Quasi-Long Pulse
  • Wavelength: 1064/532nm
  • Handpiece energy: Q-Switched Top Hat mode – 1064nm 1.6 Joule/double pulse / Gaussian mode – 1064nm 1.5 Joule/pulse / 532nm 500mJoule/pulse Quasi-Long Pulse 1064nm 3.5 Joule
  • Cooling: Closed cycle water to air heat exchanger
  • Maximum pulse energy density: Q-Switched Top Hat mode – 1064nm 22.6J/cm² @ 3.0mm spot size 532 nm 7.0J/cm² @ 3.0mm spot size Quasi-Long Pulse: 1064nm 12.3J/cm² @ 6.0mm spot size
  • Pulse width: Q-Switched – 5-10ns / Quasi-Long Pulse – 300us
  • Repitition rate: single shot, 1-20Hz pulses per second
  • Beam profile: True Flat-Top Hat
  • Energy calibration: External
  • Spot sizes: Zoom handpiece – 1064nm 2mm ~ 10mm / 532nm 2mm ~ 10mm Collimator handpiece – 6mm Fractional handpiece (optional) 5mm x 5mm (81 spots)
  • Beam delivery: Articulated arm with up to 240cm reach, 7-joint 360° rotation
